The FL series diaphragm pump is special designed for the Adblue Fitting System, it can be fitted on the side of IBC container or on the top of Ton-tank/ barrel. This pump provides a reliable solution for fitting the Adblue/DEF/Fuel,It can be widely using at the gas station,chamical machines so on, also can be using for Chemical liquid transfer,Totes or Drums of Adblue, Diesel Exhaust Fluid, Detergents, Soaps, Acids and Alkalis.
FEATURES & BENEFITS
Duty Cycle: Continous operation
Liquid Temperature: Max.60Ў (140 F)
Max. Pressure :40PSI(2.8Bar)
Self Priming: More than 3 meters
Voltage:110-240V, 50/60HZ,12V/24V DC
INVENTORY OF SYSTEM COMPONENTS
5 chamber positive displacement diaphragm pump
High pressure ,Big Flow
Self priming design ,the pump can be located above tank
Dry running without damage
Quite operation
Easy quickly connect fittings
On/Off switch easy to operation
2 meter cable with socker
